Amuse Tech Solutions LoRa Vibe Link
Amuse Tech Solutions LoRa vibe link is expertly crafted for comprehensive vibration detection and control across industrial, commercial, and general building applications.
Description
Overview
Amuse Tech Solutions LoRa vibe link is expertly crafted for comprehensive vibration detection and control across industrial, commercial, and general building applications. Ideal for large and medium-sized rotating machinery like fans, water pumps, reducers, and bearing blocks, these sensors enable direct measurement of vibration safety and temperature rise, ensuring optimal performance and reliability in various operational scenarios.
Technical Specifications
| Sensitivity | 50 mv / g |
| Acceleration Range | ±100 g |
| Frequency Range (±10 %) | 0.5 Hz to 5000 Hz |
| Resolving Power | 1 mg |
| Frequency Response | 15 kHz |
| Transverse Sensitivity | ≤5% |
| Overload Limit (Shock) | ±1000 g |
| Temperature Range (Operating) | -40 °F to 121 °F (-40 °C to 49 °C) |
| Excitation Voltage | 18 V DC to 28 V DC |
| Exciting Current Bias Current | 2 mA to 10 mA |
| Output Bias Voltage | 11 V DC to 1 V DC |
| Output Impedance | <100 Ω |
| Sensitive Parts | Ceramics, Shear |
| Housing Material | Titanium alloy |
| Electrical Connector | 5 Coaxial Jack / M 6 |
| Output Mode | 3 to M 5 |
| Weight | 0.11 lb (50 g) |
