Amuse Tech Solutions LoRa Hardware
Amuse Tech Solutions lora hardware is an edge computing LoRa gateway that comes preloaded with Linux (4.19.219 Kernel, arch 64) Debian 10 operating system.
Description
Overview
Amuse Tech Solutions lora hardware is an edge computing LoRa gateway that comes preloaded with Linux (4.19.219 Kernel, arch 64) Debian 10 operating system. IP66 waterproof, with no fan or motor cooling structure, can be used in agriculture, industrial, smart city, and other applications.
Features
- ROCKCHIP Quad-core Cortex-A 55 64-bit 1.8 GHz processor
- 2GB DDR4 RAM
- 32GB eMMC 5.1 (customizable to 8/16/64/128 GB) ROM
- LoRa Baseband: SX 1303 + SX 1250 chipset
- Pre-loaded with Linux (4.19.219 Kernel, arch64) Debian 10 operating system
- Ethernet (10/100 M), LTE (optional), Wi-Fi (optional), PoE (optional)
- Waterproof and dustproof (IP 66)
- Pre-installed Docker for easy deployment of applications
- Effective heat dissipation with a cooling fan and motor structure
Technical Specifications
| CPU | ROCKCHIP Quad-core Cortex-A 55 64-bit 1.8 GHz processor |
| RAM | 2 GB DDR4 |
| ROM | 32 GB eMMC 5.1 (customizable to 8 GB / 16 GB /64 GB / 128GB) |
| LoRa Baseband | SX 1303 + SX 1250 chipset |
| Operating System | Linux (4.19.219 Kernel, arch 64) Debian 10 operating system |
| Network Connection | Ethernet (10/100M), LTE (optional), Wi-Fi (optional), PoE (optional) |
| Waterproof and Dustproof | IP 66 |
| Pre-installed Docker | Yes |
| Heat Dissipation | Cooling fan and motor structure with unique thermal conductive device |
| Max TX Power | 26±1 dBm, 902 MHz to 928 MHz: 26±1 dBm |
| Max. Receiving Sensitivity | -139 dBm @SF 12, 125 KHz |
| Size | 4.92 in x 4.92 in x 2.05 in (125 mm x 125 mm x 52 mm) |
| Operating Temperature | -40 °F to 185 °F (-40 °C to 85 °C) |
| Weight | 1.32 lb (600 g) |
