Amuse Tech Solutions Gigabit Network Switch
Amuse Tech Solutions rack mount type gigabit network switch, is a next generation aggregation 10GE switch introduced by JT.
Description
Overview
Amuse Tech Solutions rack mount type gigabit network switch, is a next generation aggregation 10GE switch introduced by JT. It is targeted at the IP MAN (metropolitan area network), government and enterprise networks, Internet café and diskless working environment. It is developed on the basis of high performance hardware and JTROS software platform with JT own independent intellectual property rights.
Â
Technical Specifications
|
Power |
no-load | <25 W |
| full-load | < 48 W | |
| Power supply AC | AC: 100 240 V | |
| Power supply AC | DC: 36 to 72 V | |
| Total output BTU (1000B TU or H=293 W) | 163.82 | |
| Layer 2+ Switching Characteristics | VLAN | 4 K Active VLAN Â or QinQ & Selective QinQ Â or GVRP, Private VLAN Â or Voice VLAN |
| Reliability | Static or LACP link aggregation or Interface backup or EAPS and ERPS or ISSU uninterrupted system upgrade or JTVSS, ups to 16-units per stack or VRRP or UDLD | |
| MAC address table | 16 K | |
| IP | Static route, RIP, OSPF IPv4 or v6 dual stack |
|
| Management | Console, Telnet , SSH v1 or 2, HTTP, HTTPS, SNMP v1 or v2 or v3, RMO or  TFTP, FTP, SFTP · NTP · ZTP (Zero Touch Provisioning) or SPAN, RSPAN |
|
| Jumbo frame | 9 K | |
| Watchdog function | support | |
| Port trunking | support | |
| Environmental Conditions | Working temperature | 32 F to 122 F (0℃  to 50℃) |
| Storage/Transportation Temperature | 68 F to 158 F (20 ℃  to 70 ℃) | |
| Relative humidity | 5% to 95% | |
| Fan number | 2 | |
| MTBF(H) | > 200,000 | |
| Security | Forwarding mode | Store to forward |
| Flash (MB) | 16 | |
| DRAM (MB) | 512 | |
| MAC | 16 K | |
| Buffer size(Mb) | 1.5 | |
| Mechanical Structure | Dimensions | 17.32 in X 11.02 in X 1.73 in (440 x 280 x 44 mm) |
| Jumbo frame | 9 K | |
| Weight about | 12.13 lb (5.5 KG) | |
| Certification | Product certification | CE or FCC or ROHS |
