Amuse Tech Solutions Ethernet Tester
GAO Tek Ethernet Tester supports testing for speeds up to 1Gbps.
Description
Overview
GAO Tek Ethernet Tester supports testing for speeds up to 1Gbps. The TC602RE adds a suite of E1, SyncE, and IEEE1588v2 testing functions for even wider utility. It’s the next generation of telecommunication systems analysis, serving the growing need for high-speed metropolitan access and wireless backhaul at unmatched cost performance.
Features
- Complete solution for activating
- Verifying & fault-diagnosing Ethernet service
- 5” (800×480) color LCD touchscreen
- Dual or single 1000Base-X SFP ports
- Perform two measurements simultaneously
- Dual or single 10/100/1000 RJ45 ports
- Convenient and intuitive user interface
- Integrates mutiple software tools
- Ensuring high Cost-per formance
- PDF and CSV data report generation
- Rechargeable lithium battery powers
- Use for over 3.5 hours (4 hours idle)
Technical Specifications
| Application | Ethernet measurement |
| Screen | 5 in 800 x 480 color LCD touchscreen |
| RFC2544 | support |
| Y1564 | support |
| BERT | support |
| External Port | USB, LAN RJ45 |
| Working Time | 7 hours |
| Charging Time | 5 hours |
| Relative Humidity | 0 to 95 % |
| Operating Temperature | 14 °F to 122 °F (- 10 ℃ to + 50 ℃) |
| Storage Temperature | – 4 °F to 158 °F (- 20 ℃ to + 70 ℃) |
| Dimension | 7 in x 5.7 in x 2.2 in (179 mm x 145 mm x 56 mm) |
| Weight with Battery | 1.7 lb (0.8 kg) |
