Amuse Tech Solutions 8 Port Industrial POE Ethernet Switch
Amuse Tech Solutions 8 port industrial POE ethernet switch with 8 x 10 / 100 / 1000 M RJ45 ports and 2 x 1000 M uplink SFP slot or 1 x 9 SC Fiber port, Port 1 to 8 can support IEEE802.3 af / at PoE.
Description
Overview
Amuse Tech Solutions 8 port industrial POE ethernet switch with 8 x 10 / 100 / 1000 M RJ45 ports and 2 x 1000 M uplink SFP slot or 1 x 9 SC Fiber port, Port 1 to 8 can support IEEE802.3 af / at PoE. Support DC dual power supply input and DIN rail mounting.
Features
- Unmanaged industrial PoE fiber switch with 8 x 10 / 100 / 1000 M RJ45 ports
- 21 x 1000 M uplink SFP slot or 1 x 9 SC port
- Supports IEEE802.3af / at PoE on ports 1 to 8
- Non-blocking wire – speed forwarding supported
- Full duplex based on IEEE 802.3 x and half-duplex based on backpressure
- 8 x 10 / 100 / 1000 Base-T RJ45 ports for various scenarios
- Compliant with IEEE 802.3 af / at PoE standard
- PoE port priority system for power supply
- Low power consumption, finless, aluminum shell
- User-friendly panel with LED indicators
Technical Specifications
| PoE port | 1 to 8 |
| PoE Protocol | 802.3 af, 802.3 at |
| Pin Assignment | 1, 2, 3, 6 |
| PoE Mode | Standard mode |
| Switching capacity | 1 G |
| Packet forwarding rate | 0.744 Mpps |
| MAC address table | 2 K |
| Buffer | 768 K |
| Forwarding delay | <5 us |
| MDI/MDIX | Support |
| Flow Control | Support |
| Jumbo Frame | 2 K bytes |
| Operating temperature | -22 °F to 167 °F (-30 °C to 75 °C) |
| Storage temperature | -22 °F to 167 °F (-30 °C to 75 °C) |
| Relative humidity | 5% to 95% (non-condensing) |
| Thermal methods | Fan-free, natural cooling |
| MTBF | 100,000 hrs |
| IP level | IP 40 |
| Surge protection of power | IEC 61000-4-5 Level 4+ (4 KV / 2 KV) (8 / 20 us) |
| Surge protection of ethernet port | IEC 61000-4-5 Level 4+ (4 KV/2 KV) (10 / 700 us) |
| RS | IEC 61000-4-3 Level 3 (10 V / m) |
| EFI | IEC 61000-4-4 Level 3 (1 V / 2 V) |
| CS | IEC 61000-4-6 Level 3 (10 V / m) |
| PFMF | IEC 61000-4-8 Level 4 (30 A / m) |
| DIP | IEC 61000-4-11 Level 3 (10 V) |
| EMI | CLASS A |
| ESD | IEC 61000-4-2 Level 4 (8 K / 15 K) |
| Installation method | Din-rail |
| Weight | 3.31 lb (1.5 kg) |
| Product size | 7.48 in x 5.31 in x 1.77 in (190 mm x 135 mm x 45 mm) |
