Amuse Tech Solutions – 4 Antennas UHF RFID Fixed Standard Reader– With The Frequency From 860 MHz To 960 MHz
This 4 antenna RFID Reader is for industrial inventory. Aluminum body, 32.81 ft read range and robust design. Ideal for logistics and asset tracking.
Description
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Air Interface Protocol | EPC global UHF Class 1 Gen 2 or ISO 18000-6C ISO 18000-6B |
| Body Material | Die-cast aluminum |
| Input Voltage | DC 12 V to 18 V |
| Standby Mode Current | < 30 mA |
| Sleep Mode Current | < 100 uA |
| Max Operating Current | 600 mA +/-5 % at DC 12 V Input |
| Output Power | 0 dBm to 33 dBm |
| Output Power Precision | +/- 1 dB |
| Output Power Flatness | +/- 0.2 dB |
| Receive Sensitivity | < -85 dBm |
| Peak Inventory Speed | >700 tags per s |
| Tag Buffer Capacity | 1000 tags at 96 bit EPC |
| Tag RSSI | Supported |
| Antenna Detector | Supported |
| Ambient Temp Monitor | Supported |
| Working Mode | Single or DRM |
| Host Communication | RS-485 or RS-232 or TCP or IP |
| GPIO | 2 inputs optical coupling 2 outputs optical coupling |
| Max Baud Rate | 115200 bps |
| Heat Dissipation | Air cooling |
| Reading Distance | 0 ft to 32.81 ft (0 m to 10 m) |
| Writing Distance | 0 ft to 22.97 ft (0 m to 7 m) |
| Humidity | < 95 % 77 °F (+ 25 °C) |
| Operating Temperature | -4 °F to 131 °F (-20 °C to +55 °C) |
| Storage Temperature | -4 °F to 185 °F (-20 °C to +85 °C) |
| Dimension | 9.06 in x 6.30 in x 1.10 in (230 mm x 160 mm x 28 mm) |
| Weight | 3.97 lb (1.8 kg) |
