Advanced LoRa Communication Module and Power Protection – Amuse Tech Solutions
Discover the Advanced LoRa Communication Module with 850–930 MHz frequency, robust power protection.
Description
Technical Specifications
| Wireless Standards | LoRa |
| Frequency Band | 850MHz to 930MHz (customized) |
| Operating Humidity | 10% to 90% RH |
| Power Supply | 12V to 24V DC |
| Transmitted Power | 30 dBm |
| Function | LoRa communication |
| LoRa Chip Solution | LLCC68 |
| Radio Power | 30 dBm / 27 dBm / 24 dBm / 21 dBm |
| Radio Speed | 62500 / 38400 / 19200 / 19600 / 4800 / 2400 |
| Transmission Length | 200 Bytes |
| Work Mode | Normal mode or relay mode |
| Rated Voltage | DC 12V (working range: DC 12–24V) |
| Rated Power | <5W |
| Power Protection | Anti-static, anti-surge, anti-reverse connection |
| Work Mode | Master |
| Baud Rate | 115200 / 9600 / 4800 / 2400 |
| Working Temperature | -4°F to +158°F (-20°C to +70°C) |
| Storage Temperature | -40°F to +185°F (-40°C to +85°C) |
