32-Channel XLR Audio Fiber Converter with Noise Control and -7 dB Tx Power – Amuse Tech Solutions
32-channel XLR audio fiber converter with intelligent noise control, 101 dB dynamic bandwidth, and -7 dB Tx power for clear, stable transmission.
Description
Features
- Â 32-channel balanced audio
- Analog audio
- Stable FPGA technology
- XLR Cannon interface (100 dB dynamic range)
- Intelligent noise control
- Lightning protection
- LED status indicators
- Plug and play
- Transmitter and receiver pairs
Technical Specifications
| Network | None |
| Wavelength | 1310 nm & 1470 nm to 1610 nm (selection is based on device function) |
| Tx Power | >-7 dB |
| Rx Sensitivity | -24 dB |
| Fiber Connector | FC (SC, ST, LC optional) |
| Signal Level | 0.5 V to 4 Vp to p |
| Dynamic Bandwidth | 101 dB |
| Total Harmonic Distortion (THD) | -90 dB |
| Power Supply | 12 V 1 A |
| Power Dissipation | < 1.5 W |
| Sampling Frequency | 192 KHz |
